Improvements made and defects fixed on the Cable Size Calculator
Hi Reader
Just letting you know.
I made a few small improvements and fixed defects on the Cable Size Calculator.
Improvements:
- Input: Added a voltage drop select list so you don't have to type.
- Input: Added more options to the voltage select list.
- Input: Units are now shown inside input fields instead of in the label.
- Results: In loop impedance, I added "installed distance" above "maximum distance" for easy comparison.
- Results: Improved layout when no suitable cable is found.
- Step-by-step calculations. Improved formulas and descriptions for loop impedance.
- Report: Updated heading with full standard title i.e. AS/NZS 3008.1.1:2017 Australian conditions or AS/NZS 3008.1.2:2017 New Zealand conditions.
- Report: Updated loop impedance descriptions.
Defects:
- Input: The "Spaced from Surface, Touching" allowed only 6 circuits instead of 9.
- Input: The voltage select list was cut off at the end on mobile phones.
- Input: The voltage input field for "Other" voltage did not display properly on mobile phones.
- Results: Earth fault at the load not displayed for generic protection.
- Report: The aluminium 110° degree Tricab cable reference did not fit on the report.
- Report: Special characters in PDF reports were incorrectly encoded, e.g. A & B showed as A & B.
Click to try.
Please let me know if you have any questions or suggestions.
Adam van Staden
LinkedIn Profile
